N193/7.X
PROVEN PLATFORM. NEXT-LEVEL PERFORMANCE.
At a glance
ROTOR
95 M SINGLE-PIECE BLADE
+22 % SWEPT AREA COMPARED TO N175/6.X
MORE YIELD
COMPARED TO N175/6.X IN LOW-WIND CONDITIONS
START OF PRODUCTION
QUICK TIME TO MARKET
The N193/7.X
TAILORED TO LOCAL REQUIREMENTS. READY FOR GLOBAL MARKETS.
The Nordex Group is expanding its product portfolio with a powerful new addition to its globally successful Delta4000 series. The N193/7.X turbine combines a proven technology base with targeted innovations to maximize energy yield, improve permitting viability, and further increase cost effectiveness. Optimized component design, efficient space utilization, and the integration of the latest technological advancements deliver strong performance and additional value for customers.
Building on the flexibility of the Delta4000 platform, the new turbine will be available in several nominal capacity configurations, allowing developers and operators to select the ideal solution for their specific market requirements.
The N193/7.X delivers an installed capacity of 7.3 MW, paired with a 193-meter rotor and 95-meter blades. This combination ensures outstanding performance and makes the turbine a highly competitive choice for medium- and low-wind sites.
For the German market, the new turbine will initially be available with a maximum capacity of 6.6 MW, optimizing project economics at medium- to low-wind sites while addressing complex permitting and grid connection requirements.
MAXIMUM FLEXIBILITY FOR EVERY SITE
MULTIPLE MODES FOR VARIOUS SITE CONDITIONS
The N193/7.X has been designed with a flexible operating concept and will be available in multiple power modes. This enables customers to optimize the balance between energy production, noise emissions and site suitability. Depending on the selected operating mode, sound power levels range from approximately 99.5 dB(A) to 109 dB(A).
Technical Data
Operating data
Rated power
7.X
Cut-in wind speed
3 m/s
Cut-out wind speed
Up to 24 m/s
Rotor
Diameter
193 m
Swept area
29,255 m2
Gearbox
Type
High-speed gearbox
Generator
Construction
Double fed asynchronous generator
Cooling system
Liquid/air cooling
Grid frequency
50/60 Hz
Brake system
Main brake
Aerodynamic brake (pitch)
Holding brake
Disc brake
Hub height
Hub height
up to 181 m, project and site specific tower options
OPTIMIZED DESIGN BASED ON PROVEN TECHNOLOGY
YEARS OF EXPIERENCE AND PROVEN CONCEPTS
The N193/7.X builds on the proven Delta4000 platform, retaining key drivetrain, electrical and nacelle technologies to ensure high reliability and streamlined production, logistics and installation processes. To accommodate the larger 193-meter rotor, selected components have been specifically adapted: e.g. the main frame and rotor-lock system have been reinforced, while the gearbox has been redesigned. This combination of proven platform technology and targeted enhancements delivers increased performance while maintaining the robustness customers expect from Delta4000.
