N155/5.X

THE N155/5.X
EVEN MORE POWER. EVEN LOWER COE FOR MW-CONSTRAINED SITES

0107

At a glance

Higher AEP

IMPROVED AEP PER WTG

Low
COE

LOWER COST OF ENERGY

2021

CERTIFICATIONS / WTG AVAILABLE

0207

Designed for growth markets

Optimized performance for markets with less complex sites

The N155/5.X leverages already developed components of the current 5.X series – the N149/5.X and the N163/5.X – to boost annual energy production per wind turbine. This variant improves competitiveness in situations where fewer wind turbines on a grid-constrained project result in a better overall cost of energy.
This applies for many locations worldwide, but will fit optimally in much of the United States, Latin America, South Africa, and Southeast Asia, and represents a large segment of projects being developed in large growth markets.

The turbine leverages the fully tested and certified architecture of the Delta4000 nacelle,features a hydraulic hub system in conjunction with blades that have a glass fiber spar cap construction.
It capitalizes on the modular platform concept of the Delta4000 by integrating an upgraded drive train and electrical system to facilitate higher power rating. First certifications and WTG deliveries in Mid 2021.

0307

Delta4000 architecture certified on site

YouTube

By clicking on “Load video”, you consent to content being reloaded by Google (United States). This provides Google with the information that you have accessed our site as well as the technically necessary data in this context. We have no influence on the further data processing by Google. The transfer to Google may be based on the EU-U.S. Data Privacy Framework or standard contractual clauses. See further information at privacy policy

Load video

As of October 2022

PROVEN TECHNOLOGY

With the Delta4000 platform the Nordex Group builds upon the Delta Generation’s fundamental design. The N155/5.X leverages on the N155/4.X hub and nacelle components as well as blades to capture the supply chain as well as O&M synergies and benefits from existing blade & tower molds.

0407

Technical Data

Operating data

Rated power

5.X MW

Cut-in wind speed

3 m/s

Cut-out wind speed

25 m/s

Rotor

Diameter

155 m

Swept area

18,869 m²

Gearbox

Type

3-stage (planetary-planetary-spur gear)

Generator

Construction

Double fed asynchronous generator

Cooling system

Liquid/air cooling

Voltage

750 V

Grid frequency

50/60 Hz

Brake system

Main brake

Aerodynamic brake (pitch)

Holding brake

Disc brake

Lightning protection

Lightning protection

Fully compliant with IEC 61400-24

Hub height

Hub height

up to 120 m, project and site-specific

0507

The Strategy: Evolution

CONNECTING PROVEN TECHNOLOGY WITH INNOVATIVE ENGINEERING

For the Delta4000 product series, we took over the Delta
Generation’s fundamental design and transferred it to the 4 MW, 5 MW and 6 MW+ classes.

Depending on the investment criteria of the customer’s business case, the wind farm can be optimized in terms of AEP, rating, lifetime and sound requirements. In addition, this flexibility offers opportunities to optimize the revenues in line with PPA structures and merchant price profiles.

1. OPTIMIZED POWER TRANSFER
2. LARGER ROTOR DIMENSIONS
3. REDUCED SERVICE EFFORTS
4. MAINTAINED ELECTRICAL SYSTEM
5. RELIABLE DRIVETRAIN CONCEPT
6. GRID COMPATIBILITY GUARANTEED
